| IMAGE |
| Lens |
Optical Zoom 30X, 4.3~129mm |
| Angle of View |
65.1~2.23°(H) |
| Image Sensor Type |
1/2.8” SONY STARVIS CMOS Sensor |
| Image Sensor Pixels |
1945(H)x1097(V) |
| Min. Illumination |
Color : 0.35Lux / BW : 0.013Lux@50IRE, 0Lux(IR LED On) |
| Scanning Mode |
Progressive Scan |
| Wide Dynamic Range |
True WDR 100db |
| Day and Night Mode |
True Day & Night |
| Noise Reduction |
3DNR |
| Digital Zoom |
16X |
| Exposure Control |
Auto, Manual, Shutter Priority, Iris Priority |
| White Balance Control |
Auto, Fluorescent, Incandescent, Outdoor, Manual |
| Back Light Compensation |
Yes |
| Image Euect |
Flip |
| Shutter Speed |
25/30fps : Auto(1/30,000~x8sec), Manual 50/60fps : Auto(1/50,000~x8sec), Manual |
| IR Illuminator Quantity |
Synchronized IR LED, Fixed IR LED |
| IR Illuminator Angle |
5~60° |
| IR Illuminator Distance |
Up to 400m |
| VIDEO/AUDIO |
| Compression |
H.264(Baseline, Main, High Profile), MJPEG |
| Bitrate Control |
CVBR, VBR |
| Resolution |
1920×1080, 1280×1024, 1280×720/960, 704×480/576, 640×360/480, 320×240 |
| Frame Rate |
Max. 50/60fps |
| Streaming |
50/60fps(Dual Stream : H.264×1, MJPEGx1) 25/30fps(Triple Stream : H.264×2, MJPEGx1) |
| Audio Compression |
G.711 |
| Audio Streaming |
2 Way |
| PTZ FUNCTION |
| Pan Range |
360˚Endless |
| Pan Speed |
Max. 380˚/sec.(Preset) |
| Tilt Range |
-10~190˚ |
| Tilt Speed |
Max. 380˚/sec.(Preset) |
| Preset |
256 |
| Tour |
8 |
| Pattern |
8 |
| Home Function |
Yes |
| SYSTEM |
| Video Contents Analysis |
DIS, Defog, Face Detector, Tampering, Line Detector, Field Detector |
| Motion Detection Area |
16 Programmable Area(Include Area 8, Exclude Area 8) |
| Privacy Masking |
16 Programmable Zone |
| FTP Uploading |
MJPEG |
| Event Notification |
E-mail, FTP, Notification Server, XML Notification, Audio Alert, AIHM |
| Audio Alert |
User-Defined 3 Audio Files |
| Login Authority |
Administrator, Operator, Guest |
| Event Buuering FTP |
Pre : 30sec, Post : 30sec |
| Event Buuering SD Record |
Pre : 10sec, Post : 60sec |
| Manual Trigger |
4 Programmable Trigger |
| Security |
Multi User Authority, IP Filtering, HTTPS, SSL |
| Network Time Sync |
NTP Server, Synchronized Computer, Manual |
| Software Reset |
Restart, Reset, Factory Default |
| Hardware Factory Reset |
Yes |
| Auto Recovery |
Backup, Restore |
| Remote Upgrade |
Web Browsing(IE, Chrome, Safari, Firefox), SmartManager, NC-Titanium |
| SD Recording Mode |
Event, Continuous |
